MCA-P01
- 68 pin
- SMT Type (offset 0.30mm)
- Grounding Lug Optional
- Dim.: 46.50L x 6.00W x 3.30H mm
MCA-P02
- 68 pin, 3.3V
- DIP Type (Board-lock type)
- Single Slot, Guide only
- Dim.: 85.55L x 59.80W x H mm
Dim.
Base | Standoff | Total "H" |
---|---|---|
5.40 | 0.00 | 5.40 |
5.40 | 2.20 | 7.60 |
5.40 | 5.00 | 10.40 |
5.40 | 5.50 | 10.90 |
5.40 | 8.00 | 13.40 |
5.40 | 10.00 | 15.40 |
5.40 | 13.00 | 18.40 |
5.40 | 18.00 | 23.40 |
MCA-P03
- 68 pin, 5V
- DIP Type (Board-lock type)
- Single Slot, Header only
- Dim.: 22.97L x 59.90W x H mm
Dim.
Base | Standoff | Total "H" |
---|---|---|
5.80 | 5.00 | 10.80 |
MCA-P05
- 68 pin, 3.3V
- DIP Type (Board-lock type)
- Single Slot, Guide only
- Dim.: 39.00L x 59.80W x H mm
Dim.
Base | Standoff | Total "H" |
---|---|---|
5.70 | 5.00 | 10.70 |
5.70 | 8.00 | 13.70 |
5.70 | 12.00 | 17.70 |
MCA-P06
- 68 pin, 3.3V
- DIP Type (Board-lock type)
- Single Slot, Guide only
- Dim.: 55.50L x 63.00W x H mm
Dim.
Base | Standoff | Total "H" |
---|---|---|
5.70 | 5.00 | 10.70 |
MCA-P07
- 68 pin, 5V
- DIP Type (Board-lock type)
- Single Slot, Guide only
- Dim.: 58.00L x 63.00W x 9.70H mm
MCA-P08
- 68 pin, 3.3V
- SMT Type
- Single Slot, Header only
- Dim.: 20.80L x 58.00W x 5.65H mm
MCA-P09
- 68 pin, 3.3V
- DIP Type (Board-lock type)
- Single Slot, Guide only
- Dim.: 85.50L x 64.00W x H mm
Dim.
Base | Standoff | Total "H" |
---|---|---|
5.70 | 5.00 | 10.70 |
5.70 | 8.00 | 13.70 |
5.70 | 15.00 | 20.70 |
5.70 | 18.00 | 23.70 |
MCA-P10
- 68 pin, 3.3V
- DIP Type (Board-lock type)
- Single Slot, Guide & Right Ejection Bar
- Dim.: 107.00L x 67.00W x H mm
Dim.
Base | Standoff | Total "H" |
---|---|---|
5.80 | 2.00 | 7.80 |
5.80 | 5.00 | 10.80 |
5.80 | 15.00 | 20.80 |
5.80 | 18.00 | 23.80 |
